Solis | S6-GC3P40K04-NV-ND
- Solis
- 25102010020 | 3-phase | 60.8A | 4 MPPT 8 IN | PID
Article number:Solis-S6-GC3P40K
Product information
Solis-S6-GC3P40K
The Solis-S6-GC3P40K is a three-phase string inverter with a nominal power output of 40 kW. With 4 MPPTs and 42A per MPPT, this inverter supports high string currents and modern high-power solar panels. The maximum efficiency of 98.6% and a DC/AC ratio of more than 170% ensure optimum energy yield and flexibility in system design. Thanks to intelligent string monitoring and a smart I-V curve scan, deviations can be detected and resolved quickly.
Features of the Solis-S6-GC3P40K
- Max. input voltage 1100V
- Max. input current 42A
- Max. output current 60.8A
- Max. efficiency 98.6%
- 3-phase
- 4 MPPT 8 IN
- Integrated AFCI
- RS485 (optional: WiFi/LAN/GPRS with a data logging stick)
- Weight 34.9 kg
- Dimensions 508 × 612 × 288 mm
Specifications
Max. efficiency
98.6
Rated MPP-voltage
180-1000
Width
508
Max. AC Apparent Power (VA)
40000 VA
Weight
34.9
Documentation
AA) Datasheet Solis S6-GC3P40K V1.5 202507 EN ENAB) Manual Solis S6-GC3P(40-60)K V1.0 20241218 EN ENAD1) 50549-1 50549-10 Certificate Solis S6-GC3P(40-60)K ENAD2) 50549-2 50549-10 Certificate Solis S6-GC3P(40-60)K ENADZ) 61000-6-1(2,3,4) 61000-3-2(3,11,12) 62920 Certificate Solis S6-GC3P(40-60)K ENADZ) 62109-1(-2) Certificate Solis S6-GC3P(40-60)K ENADZ) IEC61000-6-1(2,3,4) 55011 301489-1(17) 62920 62109-1(-2) Certificate Solis S6-GC3 ENCA) Datasheet Solis S6-GC3P40K V1.5 202507 DE ENCD1) VDE 4105 VDE 0124 Certificate Solis S6-GC3P(40-60)K EN
